LED FLOOD LIGHTS
HFD 120W
Features
- LED life is 35K hours
- Easy installation with up to 216° tilt angle
- Copper heat-pipe for better LED heat dissipation
- Anode oxidized aluminum heatsink
- Highly reflective reflector with different beam angles
- High transparent tempered glass
- High efficient power supply with open circuit, overload, over-voltage and over temperature protections
Characteristics
| Rated supply voltage | 220-240 VAC ±10% |
| Supply frequency | 50/60Hz |
| Ambient temperature (ta) | -10 … +50°C |
| Power factor | >95% |
| Current THD | <15% |
| LED power | 120W |
| Operating humidity | 10-90% |
| IP Rating | IP65 |
| CRI | 80 |
| Beam angle | 25/60/90° |
| Lumen maintenance (L70) | >35K Hrs |
%
Power Factor
%
THD
Years Warranty
Hours of LED Life
Dimensions
Compliances
EN 61347-2-1 Lamp controlgear. Particular requirements for starting devices (other than glow starters)
EN 61347-2-13 Lamp controlgear. Particular requirements for d.c. or a.c. supplied electronic controlgear for LED modules
EN 62384 DC or AC supplied electronic control gear for LED modules. Performance requirements
EN 60598-1 Luminaires. General requirements and tests
EN 60598-2-1 Luminaires. Particular requirements. Specification for fixed general purpose luminaires
EN 55015 Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment
EN 61000-3-2 Electromagnetic compatibility (EMC) – Part 3-2: Limits – Limits for harmonic current emissions (equipment input current ≤ 16 A per phase)
EN 61000-3-3 Electromagnetic compatibility (EMC) – Part 3-3: Limits – Limitation of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment with rated current ≤ 16 A per phase and not subject to conditional connection
EN 61547 Equipment for general lighting purposes. EMC immunity requirements
Product Models
| Model | CCT (K) |
Lumen (lm) |
Beam Angle (°) |
|---|---|---|---|
| HFD-120-25–830 | 3000 | 10800 | 25 |
| HFD-120-60–830 | 3000 | 10800 | 60 |
| HFD-120-90–830 | 3000 | 10800 | 90 |
| HFD-120-25–840 | 4000 | 11400 | 25 |
| HFD-120-60–840 | 4000 | 11400 | 60 |
| HFD-120-90–840 | 4000 | 11400 | 90 |
| HFD-120-25–865 | 6500 | 12000 | 25 |
| HFD-120-60–865 | 6500 | 12000 | 60 |
| HFD-120-90–865 | 6500 | 12000 | 90 |
