Features
- LED life is 35K hours
- Easy installation with up to 216° tilt angle
- Copper heat-pipe for better LED heat dissipation
- Anode oxidized aluminum heatsink
- Highly reflective reflector with different beam angles
- High transparent tempered glass
- High efficient power supply with open circuit, overload, over-voltage and over temperature protections
Characteristics
Rated supply voltage | 220-240 VAC ±10% |
Supply frequency | 50/60Hz |
Ambient temperature (ta) | -10 … +50°C |
Power factor | >95% |
Current THD | <15% |
LED power | 500W |
Operating humidity | 10-90% |
IP Rating | IP65 |
CRI | 80 |
Beam angle | 25/60/90° |
Lumen maintenance (L70) | >35K Hrs |
%
Power Factor
%
THD
Years Warranty
Hours of LED Life
Dimensions
Compliances
EN 61347-2-1 Lamp controlgear. Particular requirements for starting devices (other than glow starters)
EN 61347-2-13 Lamp controlgear. Particular requirements for d.c. or a.c. supplied electronic controlgear for LED modules
EN 62384 DC or AC supplied electronic control gear for LED modules. Performance requirements
EN 60598-1 Luminaires. General requirements and tests
EN 60598-2-1 Luminaires. Particular requirements. Specification for fixed general purpose luminaires
EN 55015 Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment
EN 61000-3-2 Electromagnetic compatibility (EMC) – Part 3-2: Limits – Limits for harmonic current emissions (equipment input current ≤ 16 A per phase)
EN 61000-3-3 Electromagnetic compatibility (EMC) – Part 3-3: Limits – Limitation of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment with rated current ≤ 16 A per phase and not subject to conditional connection
EN 61547 Equipment for general lighting purposes. EMC immunity requirements
Product Models
Model | CCT (K) |
Lumen (lm) |
Beam Angle (°) |
---|---|---|---|
HFD-500-25-830 | 3000 | 45000 | 25 |
HFD-500-60-830 | 3000 | 45000 | 60 |
HFD-500-90-830 | 3000 | 45000 | 90 |
HFD-500-25-840 | 5000 | 47500 | 25 |
HFD-500-60-840 | 5000 | 47500 | 60 |
HFD-500-90-840 | 5000 | 47500 | 90 |
HFD-500-25-865 | 6500 | 50000 | 25 |
HFD-500-60-865 | 6500 | 50000 | 60 |
HFD-500-90-865 | 6500 | 50000 | 90 |
